PA6
Electrical grade
Provide static dissipative and electrostatic discharge protection requirements.
A3000GE10NCA2
Material：
PA6
Specification：
Anti-Static
Color：
Natural color, providing custom dyeing service
Certification：
RoHS、REACH
Package：
25kg
Property：
Long-lasting anti-static effect, reducing resistivity effectively
1. 物性標準 Materials Standard：
| 檢測項目 | Property |
測試方法 Test Method |
單位 Unit |
數值 Vaule |
|---|---|---|---|---|
| 機械性質 | Mechanical Properties | |||
| 抗張強度 | Tensile Strength | ASTM D638 | Kg/cm2 | 750 |
| 延伸率 | Elongation at Break | ASTM D638 | % | < 10 |
| 彎曲強度 | Flexural Strength | ASTM D790 | kg/cm2 | 1300 |
| 彎曲彈性模數 | Flexural Modulus | ASTM D790 | kg/cm2 | 38000 |
| 衝擊強度 |
IZOD Impact, Notched 1/8" 23°C IZOD Impact, Notched 1/8" -30°C |
ASTM D256 | kg-cm/cm |
10 |
| 硬度 |
Hardness Shore D Hardness Rockwell R Scale |
ASTM D2240 ASTM D785 |
- |
110 |
| 熱特性 | Thermal | |||
| 熱變形溫度 |
Heat Deflection Temperature (18.6kg/cm2 ) |
ASTM D648 | °C | 180 |
| 其它 | Other | |||
| 收縮率 | Shrinkage | ASTM D955 | % | 0.2~0.8 |
| 熔融指數 | Melt Index | ASTM D1238 | g/10min | - |
| 比重 | Specific Gravity | ASTM D792 | - | 1.20 |
| 灰份 | Ash Content | ASTM D482 | % | 10 |
| 含水率 | Equilibrium Moisture Content | ASTM D570 | % | < 0.3 |
| 體積阻抗 | Volume Resistivity | ASTM D257 | Ω•cm | 106~9 |
2.成形條件 Molding Condition：
| 乾燥條件 Drying | 料管溫度 Melt Temp | 射出壓力 Inject Press. |
|---|---|---|
| 80~100°C*4HR | 235~260°C | 20kg/cm2 |
附註:測試條件: 23℃, 50%RH, 24小時。以上數據會隨使用條件不同而有所改變，故此數據僅供參考。
Note:Test Conditions : 23℃, 50%RH, 24 hours.The data sheet is for your reference. And the data above will vary as the actual using condition changes.
